Delicate arches and simple cylinders in a family of lights which can be used singly or in clusters of brilliance. Aluminium heads with acrylic diffusers.

Create your own custom suspension light combining them individually or with our selection of canopies.

Suspension lamp with metal body, cylindrical aluminium head, acrylic (PMMA) lens diffuser and integrated LED. Adjustable height and individual canopy, suitable for creating compositions.

Ideal for the living room, dining room, kitchen island, bedroom, bar, restaurant, hotel and retail shop.


DRIVERS:

671000034 : (Min. 2x6,1W - Max. 3x 6,1W) 350mA / 230V / Dimmable Triac Ø 55mm drill on dropped ceiling

671000038 : (Max. 1x 6,1W) 24V & 350mA / 100V - 240V / Non dimmable Ø 40mm drill on dropped ceiling

671000043 : (2x6,1W) 350mA / 230V / Dimmable Triac Ø 80mm drill on dropped ceiling

671000061 : (Max. 1x10W) 350mA / 230V / Dimmable Triac Ø 45mm drill on dropped ceiling

671000056 : DRIVER DALI UPON REQUEST

(Min. 1x6,1W - Max. 3x6,1W)350mA / 230V / DALI Dimmable Ø 40mm drill on dropped ceiling


T-3534S

Driver included / Non dimmable

Product includes:

• 1 single canopy 113534XX0

• 1 unit of T-3534C with cable

• 1 driver 671000038 / Non Dimmable


T-3534R

Remote driver included / Dimmable Triac

Product includes:

• 1 recessed canopy 113534XX2

• 1 unit of T-3534C with cable

• 1 remote driver 671000061 / Dimmable Triac



Please follow the links below to see the other available items in the same range:

VOLTA WALL ARCH [A-353]

VOLTA WALL & CEILING LIGHT [A-3533]

VOLTA TABLE LAMP [M-3537]

VOLTA PENDANT

VOLTA FLOOR LAMP [p-3538]

VOLTA ARCH [T-3535]

VOLTA ARCH COMPOSITIONS [L7]

VOLTA ARCH COMPOSITIONS [R]

2D FILESSPEC SHEETPHOTOMETRIC CURVE
INSTALLATION INSTRUCTIONS


CATALOGUEPRICELIST
  • DESCRIPTION

    Delicate arches and simple cylinders in a family of lights which can be used singly or in clusters of brilliance. Aluminium heads with acrylic diffusers.

    Create your own custom suspension light combining them individually or with our selection of canopies.

    Suspension lamp with metal body, cylindrical aluminium head, acrylic (PMMA) lens diffuser and integrated LED. Adjustable height and individual canopy, suitable for creating compositions.

    Ideal for the living room, dining room, kitchen island, bedroom, bar, restaurant, hotel and retail shop.


    DRIVERS:

    671000034 : (Min. 2x6,1W - Max. 3x 6,1W) 350mA / 230V / Dimmable Triac Ø 55mm drill on dropped ceiling

    671000038 : (Max. 1x 6,1W) 24V & 350mA / 100V - 240V / Non dimmable Ø 40mm drill on dropped ceiling

    671000043 : (2x6,1W) 350mA / 230V / Dimmable Triac Ø 80mm drill on dropped ceiling

    671000061 : (Max. 1x10W) 350mA / 230V / Dimmable Triac Ø 45mm drill on dropped ceiling

    671000056 : DRIVER DALI UPON REQUEST

    (Min. 1x6,1W - Max. 3x6,1W)350mA / 230V / DALI Dimmable Ø 40mm drill on dropped ceiling


    T-3534S

    Driver included / Non dimmable

    Product includes:

    • 1 single canopy 113534XX0

    • 1 unit of T-3534C with cable

    • 1 driver 671000038 / Non Dimmable


    T-3534R

    Remote driver included / Dimmable Triac

    Product includes:

    • 1 recessed canopy 113534XX2

    • 1 unit of T-3534C with cable

    • 1 remote driver 671000061 / Dimmable Triac
